21479.00 – 11974 Lebanon Road Sharonville Ohio

• Do you have a Date and Time preference for survey?
  No
• Point of Contact for the building Survey
  Chris Nachtrab
• Point of Contact Job Title
  LL
• Phone Number for Point of Contact
   (513) 604-1899
• Cell Phone Number
   (513) 864-6042
• Email for Point of Contact
  chris.nachtrab@ngkf.com
• Survey Type
  • Renovation
• Type of Building
  • Strip center
• Survey Type, select all that apply:
  • Mechanical
  • Electrical
  • Plumbing
  • Fire Protection
• What is the Survey Deliverable to the client?
  • KLH issues of concern
  • KLH checklist
  • Client specific checklist
  • KLH mark ups
• Deliverable Due Date to Customer:
   Tuesday, June 25, 2019
• Please Define the Scope of the Survey:

  Typical DT survey with MEP high level items

  • Survey Deliverable
  o External (TO Dollar Tree)
   MEP Report (blank attached)
  • Executive summary of site conditions
  • Completed sections (strike thru those that do not apply)
   Electrical riser
   MEP Survey Photos Zip file (75MB max; can be split into multiple zip files if larger than 75MB)
  o Internal (For KLH internal use)
   Organized photos
   RCP
   Floor plan layouts/markups (for plumbing, mechanical, electrical)
   Structural markup (if low or odd structure)

• Upload any Documents concerning the Work Scope here















  Survey Request.pdf

• Please provide any details about the building to be surveyed not in the scope. This includes portion of building to be surveyed, how to access the building once on site and other relevant details about surveying the site that could be relevant for the onsite technician.
  n/a
• Please select all the equipment required to perform survey:
  • Video & Photos: Smartphone
  • Photos (digital camera)
  • Basic Surveying Bag
  • Ladder
• Is Revit Information available?
  No
• Do you have any other files to upload?
  Yes

<iframe src=”https://viewer.autodesk.com/id/dXJuOmFkc2sub2JqZWN0czpvcy5vYmplY3Q6YTM2MHZpZXdlci90MTU1ODM1MjYzNzY4N18wMDk5OTAzMjc2NDMyNzM3ODlfMTU1ODM1MjYzNzk0MS5ydnQ?designtype=rvt&amp;sheetId=MDFlMTRmNmUtNzYxZi02ZGZlLTRhY2QtMzBjOWJhOTI3NTMw”> width =”1000″ height =”1000″ frameborder =”1″ scrolling = “yes” align = “center”&gt;</iframe>
